GATE CE Soil Mechanics PYQs & Answers

Questions 1–10 of 103. Imported answers require independent review unless marked reviewed.

The name of a person in Column 1 is to be matched with the test mentioned in Column 2.

Option giving the CORRECT match between Column 1 and Column 2 is:

Your answerChoose one option.

(I) – (Q) ; (II) – (P) ; (III) – (S) ; (IV) – (R)

(I) – (R) ; (II) – (S) ; (III) – (Q) ; (IV) – (P)

(I) – (P) ; (II) – (Q) ; (III) – (S) ; (IV) – (R)

(I) – (R) ; (II) – (S) ; (III) – (P) ; (IV) – (Q)

You can attempt this question now. Sign in to view the answer key, explanations and discussion.Log in to check answer

Based on the Casagrande’s plasticity chart, plasticity index (in %) of inorganic clays having a liquid limit of 40 %, ranges between

Your answerChoose one option.

18.0 and 28.8

14.6 and 28.8

14.6 and 23.4

18.0 and 43.8

You can attempt this question now. Sign in to view the answer key, explanations and discussion.Log in to check answer

For a liquid, the permeability of a sandy soil having a void ratio of 0.60 was determined as 0.14 cm/s. Considering the same liquid and by using Taylor’s equation, the permeability (in cm/s) of this soil corresponding to the void ratio of 0.80 is _____ (rounded off to two decimal places).

You can attempt this question now. Sign in to view the answer key, explanations and discussion.Log in to check answer

To obtain undisturbed clay soil sample, an Area Ratio of 10 % needs to be achieved for a thin walled sampling tube. If the outer diameter of the tube is 50.8 mm, the inner diameter (in mm) is __________________ (rounded off to one decimal place).

You can attempt this question now. Sign in to view the answer key, explanations and discussion.Log in to check answer

A fully saturated sandy soil deposit has water content 20 % and specific gravity 2.65.

The critical hydraulic gradient for seepage through the soil to create the quicksand condition is __________ (rounded off to two decimal places).

You can attempt this question now. Sign in to view the answer key, explanations and discussion.Log in to check answer

An infinite slope with slope angle

consists of soil with the following properties:

Unit weight

kN/m

Cohesion

kPa

Angle of internal friction

The critical height of the slope (in m) is _____ (rounded off to two decimal places).

You can attempt this question now. Sign in to view the answer key, explanations and discussion.Log in to check answer

For a clayey soil stratum, the time required for degree of consolidation from 25 % to 50 % is 30 days.

The total time (in days) required for 90 % degree of consolidation of the same soil stratum is _____ (rounded off to the nearest integer).

You can attempt this question now. Sign in to view the answer key, explanations and discussion.Log in to check answer

A soil sample has following properties: Natural water content = 30 % Plasticity index = 40 % Liquidity index = 50 % The estimated plastic limit (in %) of the soil is ______ (rounded off to one decimal place).

You can attempt this question now. Sign in to view the answer key, explanations and discussion.Log in to check answer

The most suitable test for measuring the permeability of clayey soils in the laboratory is _____.

Your answerChoose one option.

Constant head test

Pump out test

Hydrometer test

Falling head test

You can attempt this question now. Sign in to view the answer key, explanations and discussion.Log in to check answer

The results of a consolidated drained triaxial test on a normally consolidated clay are shown in the figure. The angle of internal friction is

Diagram for Civil Engineering question 17

Your answerChoose one option.

You can attempt this question now. Sign in to view the answer key, explanations and discussion.Log in to check answer
